2.5x12 Hydraulic Cylinder - 2.5 Bore 12 Stroke Double Acting Tie Rod Hydraulic Cylinder 2500 PSI

Tie-rod end hydraulic cylinders are widely used in industrial machinery and equipment, including hydraulic presses, machine tools, agricultural machinery, construction equipment, material handling systems, and more. They are favored for their robustness, versatility, and ease of maintenanceTie-rod end hydraulic cylinders are typically constructed with a cylindrical barrel, end caps, piston, piston rod, seals, and tie rods. The barrel houses the piston, which divides the cylinder...

2.5x12 Hydraulic Cylinder - 2.5 Bore 12 Stroke Double Acting Pin Eye Hydraulic Cylinder 3500 PSI

Bore 2.5" (OD 2.38"), Stroke12" Rod:1.375, Retracted: 20" , Extended: 28" , Pin holes: 0.75" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 14720Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x12 Hydraulic Cylinder - 2.5 Bore 12 Stroke Double Acting Welded Clevis Hydraulic Cylinder 3000 PSI

Bore 2.5" (OD 2.88"), Stroke12" Rod:1.5, Retracted: 22.25" , Extended: 34.25" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3000 PSI, Column Load Capacity of 14720Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x12 Hydraulic Cylinder - 2.5 Bore 12 Stroke Double Acting Welded Tang Hydraulic Cylinder 3500 PSI

Bore 2.5" (OD 2.88"), Stroke12" Rod:1.5, Retracted: 21" , Extended: 33" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 17670Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x12 Hydraulic Cylinder - 2.5 Bore 12 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore:2.5" (OD 2.88")., Stroke:12", Rod:1.5", Retracted:20", Extended:32", Pin holes:1" Double Acting Hydraulic Cylinder with SAE#8 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 14,720 LBs, Welded Cross Tube Cylinder Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility and Universal...

2.5x14 Hydraulic Cylinder - 2.5 Bore 14 Stroke Double Acting Welded Clevis Hydraulic Cylinder 3000 PSI

Bore 2.5" (OD 2.88"), Stroke14" Rod:1.5, Retracted: 24.25" , Extended: 38.25" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3000 PSI, Column Load Capacity of 14720Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x14 Hydraulic Cylinder - 2.5 Bore 14 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore: 2.5" (OD 2.88"), Stroke: 14 inches, Rod: 1 1/2", Retracted: 22", Extended: 36", Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE 8 Ports (O-ring boss), Rated Pressure: 3500 PSI, Column Load Capacity: 14720 l lbs. Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust...

2.5x16 Hydraulic Cylinder - 2.5 Bore 16 Stroke Double Acting Tie Rod Hydraulic Cylinder 2500 PSI

Tie-rod end hydraulic cylinders are widely used in industrial machinery and equipment, including hydraulic presses, machine tools, agricultural machinery, construction equipment, material handling systems, and more. They are favored for their robustness, versatility, and ease of maintenanceTie-rod end hydraulic cylinders are typically constructed with a cylindrical barrel, end caps, piston, piston rod, seals, and tie rods. The barrel houses the piston, which divides the cylinder...

2.5x16 Hydraulic Cylinder - 2.5 Bore 16 Stroke Double Acting Welded Clevis Hydraulic Cylinder 3000 PSI

Bore 2.5" (OD 2.88"), Stroke16" Rod:1.5, Retracted: 26.25" , Extended: 42.25" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3000 PSI, Column Load Capacity of 14720Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x16 Hydraulic Cylinder - 2.5 Bore 16 Stroke Double Acting Welded Tang Hydraulic Cylinder 3500 PSI

Bore 2.5" (OD 2.88"), Stroke16" Rod:1.5, Retracted: 25" , Extended: 41" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 17670Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x16 Hydraulic Cylinder - 2.5 Bore 16 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore: 2.5" (OD 2.88"), Stroke: 16 inches, Rod: 1 1/2", Retracted: 24", Extended: 40", Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE 8 Ports (O-ring boss), Rated Pressure: 3500 PSI, Column Load Capacity: 14720 l lbs. Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust...

2.5x18 Hydraulic Cylinder - 2.5 Bore 18 Stroke Double Acting Tie Rod Hydraulic Cylinder 2500 PSI

Tie-rod end hydraulic cylinders are widely used in industrial machinery and equipment, including hydraulic presses, machine tools, agricultural machinery, construction equipment, material handling systems, and more. They are favored for their robustness, versatility, and ease of maintenanceTie-rod end hydraulic cylinders are typically constructed with a cylindrical barrel, end caps, piston, piston rod, seals, and tie rods. The barrel houses the piston, which divides the cylinder...

2.5x18 Hydraulic Cylinder - 2.5 Bore 18 Stroke Double Acting Welded Clevis Hydraulic Cylinder 3000 PSI

Bore 2.5" (OD 2.88"), Stroke18" Rod:1.5, Retracted: 28.25" , Extended: 46.25" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3000 PSI, Column Load Capacity of 12500Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x18 Hydraulic Cylinder - 2.5 Bore 18 Stroke Double Acting Welded Tang Hydraulic Cylinder 3500 PSI

Bore 2.5" (OD 2.88"), Stroke18" Rod:1.5, Retracted: 27" , Extended: 45" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 16820Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x18 Hydraulic Cylinder - 2.5 Bore 18 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore: 2.5" (OD 2.88"), Stroke: 18 inches, Rod: 1 1/2", Retracted: 26", Extended: 44", Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE 8 Ports (O-ring boss), Rated Pressure: 3500 PSI, Column Load Capacity: 14720 l lbs. Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust...
