2x10 Hydraulic Cylinder - 2 Bore 10 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke10" Rod:1.25, Retracted: 18" , Extended: 28" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 9420Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2x10 Hydraulic Cylinder - 2 Bore 10 Stroke Double Acting Tie Rod Hydraulic Cylinder 2500 PSI

Bore 2" (OD 2.38"), Stroke 10" Rod:1.125, Retracted: 20.25" , Extended: 30.25" , Pin holes: 1" Double Acting Hydraulic Cylinder with3/8" NPTPorts (Female Pipe), Rated Pressure of 2500 PSI, Column Load Capacity of 7850Lbs Tie-rod end hydraulic cylinders are widely used in industrial machinery and equipment, including hydraulic presses, machine tools, agricultural machinery, construction equipment, material handling systems, and more. They are favored for their...

2x14 Hydraulic Cylinder - 2 Bore 14 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke14" Rod:1.25, Retracted: 22" , Extended: 36" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE 6 Ports (O-ring boss), Rated PWelded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 9420Lbs. Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh...

2x22 Hydraulic Cylinder - 2 Bore 22 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke22" Rod:1.25, Retracted: 30" , Extended: 52" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 8600Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2x32 Hydraulic Cylinder - 2 Bore 32 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke32" Rod:1.25, Retracted: 40" , Extended: 72" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 5080Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2x36 Hydraulic Cylinder - 2 Bore 36 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke36" Rod:1.25, Retracted: 44" , Extended: 80" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 4120Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2x8 Hydraulic Cylinder - 2 Bore 8 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke8" Rod:1.25, Retracted: 16" , Extended: 24" , Pin holes: 1" Welded Double Acting Hydraulic Cylinder with SAE#6 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 9420Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

3.5x10 Hydraulic Cylinder - 3.5 Bore 10 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 3.5" (OD 3.88"), Stroke10" Rod:1.75, Retracted: 20" , Extended: 30" , Pin holes: 1.25" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 28860Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

3.5x18 Hydraulic Cylinder - 3.5 Bore 18 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 3.5" (OD 3.88"), Stroke16" Rod:1.75, Retracted: 26" , Extended: 42" , Pin holes: 1.25" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 28860Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

3.5x8 Hydraulic Cylinder - 3.5 Bore 8 Stroke Double Acting Welded Cross Tube Hydraulic Cylinder 3500 PSI

Bore 3.5" (OD 3.88"), Stroke8" Rod:1.75, Retracted: 18" , Extended: 26" , Pin holes: 1.25" Welded Double Acting Hydraulic Cylinder with SAE#8 Ports (O-ring boss), Rated Pressure of 3500 PSI, Column Load Capacity of 28860Lbs Superior Build Quality: All-Welded Design, Heavy-Duty Steel Construction, High Strength, and Impact Resistance to withstand Corrosion and Harsh Outdoor Conditions; High-Quality Compact Seals Prevent Leakage and Rust Particles. Strong Compatibility...

2.5x14 Hydraulic Cylinder - 2.5 Bore 14 Stroke Welded Double Acting Swivel Eye Hydraulic Cylinder 3500 PSI

Bore 2.5" (OD 2.88"), Stroke 14" Rod:1.5, Retracted: 24" , Extended: 38" , Pin holes: 1" Double Acting Hydraulic Cylinder with SAE#8 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 14720 Lbs Swivel Ball Welded Hydraulic Cylinder Features a swivel eye on both ends, providing flexibility and smooth motion in a variety of industrial, agricultural, and mobile applications. Precision-welded end caps,...

2x10 Hydraulic Cylinder - 2 Bore 10 Stroke Welded Double Acting Swivel Eye Hydraulic Cylinder 3500 PSI

Bore 2" (OD 2.38"), Stroke 10" Rod:1.25, Retracted: 20" , Extended: 30" , Pin holes: 1" Double Acting Hydraulic Cylinder with SAE#8 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 9420 Lbs Swivel Ball Welded Hydraulic Cylinder Features a swivel eye on both ends, providing flexibility and smooth motion in a variety of industrial, agricultural, and mobile applications. Precision-welded end caps,...

1.5x6 Hydraulic Cylinder - 1.5 Bore 6 Stroke Welded Double Acting Swivel Eye Hydraulic Cylinder 3500 PSI

Bore 1.5" (OD 1.88"), Stroke 6", Rod 1", Retracted 13 1/4", Extended: 19 1/4" Pin holes 3/4". Double Acting Hydraulic Cylinder with SAE#8 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 5300 Lbs Swivel Ball Welded Hydraulic Cylinder Features a swivel eye on both ends, providing flexibility and smooth motion in a variety of industrial, agricultural, and mobile applications. Precision-welded end...

1x6 Hydraulic Cylinder - 1 Bore 6 Stroke Welded Double Acting Swivel Eye Hydraulic Cylinder 3500 PSI

Bore 1" (OD 1.38"), Stroke 6", Rod 1", Retracted 13 1/4", Extended: 19 1/4" Pin holes 1/2". Double Acting Hydraulic Cylinder with SAE#8 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 2350 Lbs Swivel Ball Welded Hydraulic Cylinder Features a swivel eye on both ends, providing flexibility and smooth motion in a variety of industrial, agricultural, and mobile applications. Precision-welded end...

5x21.5 Hydraulic Cylinder for Dump Trailer – 5" Bore x 21.5" Stroke, 3500 PSI Double Acting Dump Hoist Hydraulic Cylinder, Welded Steel Trailer Hoist Cylinder (5x21.5)

Bore 5" (OD 5.38"), Stroke 21.5" Rod:2, Retracted: 29.37" , Extended: 50.87" , Pin holes: 0.63" Double Acting Hydraulic Cylinder with SAE#6 Ports (Female Pipe), Rated Pressure of 3500 PSI, Column Load Capacity of 57,000 Lbs Swivel Ball Welded Hydraulic Cylinder Multiple Applications – Ideal for dump trailers, dump beds, tilt trailers, scissor hoists, and other hydraulic lifting systems. Select the correct bore, stroke, mounting...
